SunGoldPower 3000W 24V Solar Inverter Charger - Off Grid Stores
by SunGoldPower
SunGoldPower 3000W 24V Solar Inverter Charger
SKU SPH302480A
Save $105.99 Save $105.99
$704.99
$704.99 - $704.99
$704.99
$599.00
$599.00 - $599.00
$599.00
Availability:
in stock, ready to be shipped

Free shipping with delivery betweenandOrder within

Promotion

Save An Extra

15

% Today!

Use Code

SGP15

at Checkout

Free Shipping

Every Off Grid Stores Product Ships For Free

No Sales Tax

We Only Charge Sales Tax In Nevada

Authorized Dealer

We are authorized dealers of every brand on our website

2-Year Warranty

Off Grid Stores is an authorized retailer of all brands on our website. Because of this we pass on the manufacturer's warranty to you.

Product Highlights

- All-in-one solar charge inverter: 3000 Watts Pure Sine Wave Inverter Combined with 60A MPPT solar charging and 40A AC battery charging ,you can enjoy the stable power from the sun and the utility grid to keep you powered under any circumstances.

- Four charging modes: AC Priority, Solar Priority, Only Solar and Mains & Solar hybrid charging, Designed with LCD/LED dynamic display of system data and operating status.

- Uninterruptible Power Supply: If main/generator disconnected or the solar charging insufficient, the Inverter Charger takes over the battery supply to the alternative option within 10ms, which will not let your electronics shut down.

- Battery type: 24V AGM/Sealed, Gel, Flooded, Lithium batteries and a User Mode for custom inputs to work with virtually all battery types.

- Reliable protection: including short circuit protection, over voltage and under voltage, protection, overload protection, reverse protection, etc.

Main Features:
- Built-in 60A MPPT solar charge controller, max PV input 1400W
- 40A Smart AC charger
- High frequency transformer-less compact design
- Pure sine wave AC 120V output with 50hz/60hz switch
- Optional WiFi/ GPRS remote monitoring (extral cost)
- Overload, short circuit, over discharge protection
- Auto-start the generator ( Dry Contacts for delivering signal)

Why Buy From Us?

- Help Support Small Family Owned Business

- Our Team Has Actual Knowledge Of Our Products

- You Will Talk To A Real Person In The USA When You Call

- We Guarantee To Match The Lowest Prices On The Internet

- Our Items Are Located In The USA

- We Actually Live Off-Grid Unlike Some Of Our Competitors

SunGoldPower 3000W 24V Solar Inverter Charger

SUNGOLDPOWER 3000W 24V solar inverter combines solar charging, AC/generator battery charging and battery inverter into one complete unit to make your off-grid system working. This solar inverter charger is compatible with 24V battery packs. It provides four user-configurable AC/solar charging modes and three load output modes. It can turn your system into an uninterruptible power supply (UPS )with only 10 milliseconds automatically switching to off-grid to ensure the load powered.





MODEL 3000W 24V
Inverter Mode:
Output Pure Sine Wave
Peak Power 6000VA
AC Output 120VAC ,50HZ/60HZ
Input Voltage / Rated Battery 24VDC (minimum start-up voltage 22V)
Bypass Breaker Current 40A
Idle Power 50W
Power Saver Mode Idle Consumption 25W
MPPT Solar Charging Mode:
Maximum Input Power 4000W
PV Charging Current 0-80A
Max.PV Open Circuit Voltage 450V
PV Operation Voltage Range 120-450VDC
MPPT Voltage Range 120-400VDC
Recommended Wire 8 AWG
AC Charging Mode:
Rated AC input 110V, 50HZ/60HZ
Input Voltage Range 90VAC-140VAC
Conversion Time 10ms
Battery Type Lead Acid and Lithium Battery
Maximum Charging Current 40A
Charging Voltage Range 20-33VDC
Short-Circuit Protection Breakers and fuses
Overcharge Protection Yes. Automatically alerts and turns off charging after 1 min
Mechanical Specification:
Size 14.96 x 11.03 x 4.06 inch
Net Weight 6.8KG
Noise ≤60dB
Operating Temperature Range 5°F ~ 131°F/ -15°C ~ 55°C
Cooling Fan Yes

We offer Free Shipping to the continental 48 United States on all items in our store! Currently we do not ship internationally nor do we ship to Alaska, Hawaii, US Protectorates, P.O. Boxes, APO, FPO, or DPO addresses.

All orders are processed and shipped from our warehouse within 1-3 Business Days of an order being placed (this excludes weekends and holidays).

After leaving our warehouse expect your order to arrive in 3-4 Business Days. This brings the average total shipping and handling time to 4-7 Business Days.

You can learn more about our Shipping & Handling Policy here.

While shopping at Off Grid Stores know that returns are a breeze! If you are not completely satisfied with your purchase, for any reason, you may return it to us within 30 Days of delivery for a refund.

If you would like to open up a return you can send us an email to returns@offgridstores.com with your name, order number, and reason for return.

To learn more about our Returns & Refunds Policy you can do so here.

User Manual:

SunGoldPower 3000W 24V Solar Inverter Charger User Manual


Download Now >
