Currently, it only supports connecting the DELTA Pro Ultra X via the EcoFlow Smart Inlet Box Connection Cable (5P8 Port to 5P8 Port) or connecting the DELTA Pro Ultra to the Smart Inlet Box (Smart Home Panel 2 Upgrade) via the EcoFlow Power Input/Output Cable. You can also connect the DELTA Pro Ultra X and the DELTA Pro Ultra simultaneously using the cables that meet the corresponding requirements.Currently, it does not support connecting the DELTA Pro 3. For future updates, please refer to the official information.

No, the Smart Home Panel 3/Smart Gateway is not a grid-connected system. The power of the Backup Battery will only be supplied to the branch circuits inside the system and the Sub-Panel connected to the Smart Gateway, and will not be output to the power grid.The Smart Home Panel 3/Smart Gateway only indirectly utilizes the existing photovoltaic system and will not affect its original functions.

It supports 3 - 12kW split - phase 240V generators. Connect it to the AC1 - 5p8/GEN IN port of the Smart Inlet Box (Smart Home Panel 2 Upgrade) via the EcoFlow AC Generator Charging Adapter (NEMA L14 - 30P to 5P8 Port) (allowing the generator to generate 3 - 7.2kW) or the EcoFlow Generator Charging Adapter (NEMA 14 - 50P to 5P8 Port) (allowing the generator to generate 3 - 12kW). In addition, we need to remind you that you must connect at least one DELTA Pro Ultra X/DELTA Pro Ultra to the AC2/3 port of the Smart Inlet Box for the generator to generate electricity.

Rated current: 160A; Peak current: 200A

The protection level of the Smart Home Panel 3/Smart Gateway is NEMA 3R, which is waterproof and can be installed indoors or outdoors.However, the Smart Inlet Box (Smart Home Panel 2 Upgrade) used in conjunction with it has a protection level of NEMA 1, is not waterproof, and can only be installed indoors.

Enabling the EPS mode allows the system to switch to the powered-on Backup Battery within 20ms during a power outage, reducing the impact of power outages on the important loads in your home.*Note that for the EPS to take effect within 20ms, a powered-on DELTA Pro Ultra X must be included in the connected Backup Battery.*When using only the DELTA Pro Ultra, the EPS mode and Operating modes cannot be enabled simultaneously; and if the DELTA Pro Ultra is in the charging state, it cannot switch to the DELTA Pro Ultra for power supply within 20ms at the moment of a power outage.

It is not supported. Only 2.4G WiFi is supported when connected via WiFi.

The Smart Home Panel 3/Smart Gateway supports household electricity of 120/240V~ (split phase) and commercial electricity of 208Y/120V~, 3W (from 3Ø 4W). You just need to ask your electrician to find the corresponding live wire, connect the wires according to the Installation Guide, and select the corresponding voltage in the Grid Setting of the APP.

The Smart Home Panel 3/Smart Gateway must be installed by EcoFlow authorized installers and licensed electricians, and the installers must have successfully completed the EcoFlow product training. If you are interested in contacting an authorized installer, please select the Installation Service when making a purchase. If you already have installers but they haven't obtained the relevant materials for installing EcoFlow products, please go to Support->User Manual on the EcoFlow official website and download the latest Installation Guide for the corresponding product so that they can start learning and performing the installation.

The installation time of the Smart Home Panel 3/Smart Gateway may vary depending on the scope of work required and the current wiring configuration of your home. For most households, the Smart Home Panel 3 can be installed within 10 hours, and the Smart Gateway can be installed within 6 hours.

When your system is equipped with solar panels or your household electricity price has peak and off-peak periods, you can choose AI Mode or Self-powered Mode according to your household situation. Charge the battery during low electricity price periods or when *solar energy is predicted to be available, and use the battery to power your home during high electricity price periods or when there is redundant solar energy. In addition, you can also use the Smart Circuit Settings to turn on/off some circuits with high standby power consumption at a scheduled time, and only run them when necessary.*Solar forecast requires subscribing to the professional feature package - Energy Master. For specific subscription rules and feature details, please refer to the latest information in the APP.

The Smart Home Panel 3/Smart Gateway is compatible with industry-standard single-pole and double-pole circuit breakers. For specific Main Circuit Breakers and Branch Circuit Breakers, please refer to the Circuit Breaker Compatibility section in the Installation Guide.

There are already 5 knockouts reserved on the body of the Smart Home Panel 3/Smart Gateway. If you still need more cable holes, it is recommended that you use a hydraulic hole puncher and keep the plastic protective cover inside the machine in place during the punching process to prevent iron filings and other debris from damaging the machine during the process.

Yes, but please note that when used as a Sub-Panel, you need to remove the Main bonding jumper between the Main neutral terminal and the Main ground terminal.

Both the Smart Home Panel 3 and the Smart Gateway have an EPO port reserved inside the product. When you have a need, you can optionally purchase an Emergency Power Off Button when buying the main product and install it according to the Installation Guide in the Support -> User Manual on the official website.

You can install an overcurrent protection device [OCPD] in the middle of the Smart Inlet Box Connection Cable (5P8 Port to 5P8 Port). The actual OCPD specifications shall comply with your local electrical regulations. We recommend that you use a 70A 2P circuit breaker.

You need APP version ≥ 6.8.5 to add Smart Home Panel 3 or Smart Gateway to the APP for use.
