Rich Solar 10 Amp PWM Waterproof Solar Charge Controller

Rich Solar 10 Amp PWM Waterproof Solar Charge Controller

FEATURES AND ADVANTAGES

  • PWM technology, switching control by MOSFET
  • Common Positive Grounding connection
  • High efficiency and low power consumption
  • Battery type setting via DIP switch
  • Smart charging control
  • Charging time management
  • LED indication for the battery condition and charging statues
  • Thermal protection
  • No sparks
  • Waterproof
  • Solid-duty cables
  • Corrosion-resistant terminals and connectors.
  • Conformal coating supplied to the inside board against moisture
  • Includes a port for external battery temperature sensor (BTS - optional)
  • Suitable for most of the rechargeable Lead acid battery, including Flooded (WET), AGM, GEL, Lithium (LiFePO4) battery
  • Designed according to CE standard, EMC, FCC compliance
  • Overvoltage protection, short circuit protection, reverse polarity protection

MOUNTING THE DEVICE

The quickest and easiest way to mount the unit is to use the three plastic spacers and self-tapping screws supplied and mount
the unit to a flat surface.

Specifications:

Rich Solar 10 Amp PWM Waterproof Solar Charge Controller
SKU RS-PWM10WP
ELECTRICAL PARAMETERS
Rated solar panel amps 10AMP Max.
Normal input Solar cell array voltage 15-22VDC
Max. solar cell array voltage (output has no load) 25VDC Max.
The controller lowest operating voltage (at solar or battery side) 8VDC Min.
Standby current consumption at night 5mA Max.
Maximum voltage drop-Solar panel to battery 0.25VDC Max.
CHARGING CHARACTERISTICS
Minimum battery start charging voltage 3VDC Min.
Soft start charging voltage 3-10±0.2VDC
Soft start charging current (50% PWM duty) Up to 5AMP
Bulk charge voltage 10-14±0.2VDC
Equalization charging voltage at 25 ℃ 15.5±0.2VDC
Equalization charging timer timed out 2 Hours
Battery temperature compensation coefficient -24mV/°C
Temperature compensation range -20~+50°C
PROTECTION
Over temperature protection during charging 65°C
ELECTRICAL PARTS
Input output terminal M5 terminals
PHYSICAL PARAMETERS
Controller material Plastic, Standard ABS
Power terminal maximum stranded wire size #10AWG stranded-5mm²
Mounting Vertical wall mounting
IP grade IP65
Net weight Approx. 0.66lbs
ENVIRONMENTAL CHARACTERISTICS
Operating temperature -25~50°C(-13~122℉)
Storage temperature -40~85°C(-40~185℉)
Operating Humidity range 100% no condensation
